Infrared ceramic heater use conductor containing more than 95% silicon and quartz glass hich can resist 1800°C as main material.
They create infrared radiation after chemical reaction. The spiral Cr20Ni80 resistance wire is cast into the conductor. With its advantages in thermal efficiency, radiation, safety and energy conservation, infrared ceramic heaters are widely used in plastics, chemicals, light industrial, electronic, pharmaceutical, food and other industries. It's mainly used for vacuum forming, curing paint drying, bakery, medicine dehydration, and medical care.
Fetures:
1. Cr20Ni80 resistance wire
2. HIgh watt density
3. ISO9001, CE and RoHS certified
4. Various sizes and colors to your needs
Size as followes
|
Model |
Size(mm) |
Voltage(V) |
Power(W) |
Key Technical Indexes |
|
L245Χ60 |
L245Χ60 |
230 |
650 |
3.Insulation resistance:≥5MO |
|
L120Χ60 |
L120Χ60 |
230 |
325 |
4.Ground resistance:<0.1O |
|
L120Χ120 |
L120Χ120 |
230 |
500 |
5.Voltage resistance: no electric breakdown for 1 minute under 1500V |
|
Note: Other models are available according to your specifications. Please refer to the Order Guide |
6.Temperature endurance:100-1200°C |
|||
Applications:
Thermoforming & Vacuum Forming Machines: as thermoforming heater
PVC Pipe Belling / Socketing Machines
Hot Stamping Machines
Heat Therapy Equipment
Shrink Packaging
